Backlight Color of Buttons and Display: White
Number and Type of Buttons: 5 touch buttons
Maximum Front Glass Thickness: 6 mm
Motor Speed Control: 4 speeds
Controller Board Supply Voltage: 180–250 V
Operating Temperature: 0–85 °C
Motor Compatibility: Single-phase AC induction motor
Light Type: 12 V DC
Accessories: External temperature sensor and IR remote control
Maximum Remote Control Range: 5 meters
Automatic shutdown mode after 8 hours of operation.
Automatic motor speed control based on ambient temperature.
Programmable shutdown timer.
Automatic calibration of touch buttons for different environments.
Fully electronic operation, eliminating mechanical relays used for motor startup.
Use of a switching power supply to improve efficiency, increase the current capacity of light outputs, reduce circuit weight and size, and minimize heat losses.
Light output current: 300 mA, upgradeable to 600 mA.
Compatible with various 12 V DC lighting types.
Reduces motor stress and extends motor lifespan through zero-crossing detection technology.
